In the figure below, all components of the OSC482X are presented: Manual and software are not included, you need to download them from the internet.
#Sainsmart oscilloscope driver download generator
The lower compartment contains all cables and the function generator module. The USB oscilloscope is placed in the upper compartment, well protected against possible damage of the package. All components are in a sturdy cardboard box. Because we do not need Android support we have selected model OSC482X for this test.Ĭompared to the low Chinese packaging standards, the OSC482X is delivered in a very neat way. So you can start with the cheap basic model OSC482 that costs about € 60.00 and buy the extra modules afterwards. All types have a bandwidth of 2 x 20 MHz, a sampling rate of up to 50 Msa/s and can work with all versions of Windows via the software OSC48XXC.exe.Ī short overview of the differences between the types:īasic model + function generator module + logic analyzer module.īasic model + Android support + function generator module + logic analyzer module.īasic model + Android support + function generator module + logic analyzer module + differential input module.Īll additional modules can be purchased separately.
In the series OSC482 seven types are available.
This USB oscilloscope in an original design is developed by the Chinese LOTO Instruments and sold through the well known internet channels. Introduction to the OSC482X from LOTO Instruments A set that is more than worth a comprehensive review. For about 100 euros you get a two channel USB oscilloscope with a bandwidth of 20 MHz and a sampling rate of 50 Msa/s, a datalogger, a function generator and a four channel logic analyzer.
